Our 1,000-volt composite wires offer exceptional flexibility in smaller-diameter, lightweight constructions for applications requiring total temperatures of up to 260 °C. The wires provide excellent arc-propagation resistance, a minimum bend radius of 6x, and flexible high-strand-count conductors for easy handling in tight spaces. These wires feature:

• A nickel-plated copper shield that offers electromagnetic interference (EMI) protection or can be used for ground fault detection
• Seamless™ Wrap PTFE jacket technology which offers all the advantages of tape wrap, with a smooth outer surface that improves installation characteristics
• Highly flexible conductor strands which make the cable easy to work with on the production floor


  Features & Benefits

  Features	Benefits
  High-voltage performance of 1,000 V	• Corona resistant
  Shielded construction	• EMI protection • Ground fault detection
  Minimum bend radius of 6x	• Allows routing around tight bends and in restricted areas
  UV laser marking	• Easily identify wire for customers and end-users
  Seamlesss™ jacket construction	• Smooth appearance and installation characteristics of an extrusion
  Exceptional arc-propagation resistance	• Key safety factor for customers and end users
  High-strand-count conductor	• Extremely flexible for installation and routing purposes

  Connectors for Shielded & Unshielded Cable Applications

  Whether for an air taxi operating at 1,000 VAC and 1,500 VDC at 15,000 ft., or a military aircraft operating at 3,600 VAC and 5,100 VDC at 55,000 ft., we have the expertise to engineer and produce the right connector for your shielded and unshielded cable applications. Contact us for details.
